Metal detector conveyor belt

General Technical Specifications

PU Conveyor Belts

• Working temperature: -10°C to +80°C

• Features: Oil-resistant, tear-resistant, cold-resistant, anti-abrasion

• Colors: White, Blue (enhanced contrast for metal detection)

• Certifications: FDA, HACCP, SGS/ISO

• Reference codes: U0.8NT, Ropanyl EM 4/1 00+02, EM 5/2 00+015, EM 3/1 00+02

PVC Conveyor Belts

• Key property: Carbon-fabric antistatic layer (AS) – optimized for metal detector machines

• Surface options: Glossy / Matt

• Colors: Blue, White

• Thickness: 2.0 – 5.0 mm

• Reference codes: Flexam EM 8/2 0+04 Green AS, Nonex EM 8/2 0+05 White FG AS, PVC-G20AS, PVC-D30AS

Plastic Modular Belts

• Material: PP / POM with high heat resistance and abrasion resistance

• Structure: Modular interlocking design – 100% non-metallic plastic rods

• Temperature range: -40°C to +100°C

• Pitch options: 12.7 / 25.4 / 50.8 mm

• Surface types: Closed-top / Open-top (drainage)

• Reference brands: Intralox, Habasit, Hongbelt (common series)
