The 25mm pitch homogeneous PU conveyor belt is a positively driven conveyor system powered by sprockets. Made from solid polyurethane (PU), it offers excellent durability, superior hygiene, and full compliance with food safety standards.

With a 25mm pitch, this belt ensures smooth and stable operation, eliminates slippage, and delivers precise and efficient power transmission across sprocket and pulley systems. It is an ideal solution for the food industry and other applications requiring high hygiene standards.

Advantages of 25mm Pitch Homogeneous PU Conveyor Belts

  • Made from solid TPU material, ensuring maximum food safety and hygiene
  • Suitable for small pulley systems, with stable operation and no slippage thanks to positive drive
  • High resistance to oil, grease, and abrasion → extending belt lifespan and reducing replacement costs
  • Easy to clean and water-saving → lowering maintenance costs and total cost of ownership
  • Versatile for various conveying positions with a cost-effective solution

Brands of 25mm Pitch Homogeneous PU Conveyor Belts

Ammeraal Beltech – Soliflex FB Mini (Full Bar Mini)

  • Positive drive system ensures stable operation via lateral drive bars
  • High hygiene level, compliant with food processing standards
  • Anti-stick surface for efficient product handling
  • Scraper-friendly design for easy cleaning and fast maintenance

Habasit – CD M25

  • Pitch: 26.8 mm (≈ 1")
  • Minimum pulley diameter: Ømin = 60.1 mm
  • Elongation at 1%: K1%rel = 6 N/mm

Available models:

  • CD.M25.S-UA.WB (White)
  • CD.M25.S-UA.CB (Blue)

Intralox – S8026 Series (Polyurethane)

  • S8026 Flat Top E (5.3 mm)
  • S8026 Flat Top E (6.0 mm) V2
  • S8026 Embedded Diamond Top E (6.3 mm)
  • S8026 Nub Top™ (6.3 mm / 7.4 mm)
  • S8026 Flat Top E (6.0 mm) Cold Use
  • S8126 Flat Top (6.0 mm) Polyurethane

Ino Belt

  • REO-T25 SB: Positive drive belt designed for small pulley applications, available in blue
  • REO-M25 DB: Heavy-duty homogeneous belt, ideal for pork and beef processing industries with strict hygiene requirements
  • REO-T25 DB LT: Suitable for small pulleys, even in low-temperature environments

Volta – Mini SuperDrive & Mini DualDrive

  • High-performance positive drive belts with excellent durability and easy maintenance
  • Multiple product codes available for different applications

Mafdel – DEL/DRIVE® 25

Homogeneous PU belt designed for demanding hygienic environments

Chiorino – ProDrive F-S 28/25 GS LB

Advanced PU conveyor belt optimized for food-grade applications

Accessories

  • Flights (cleats) – Assist in inclined conveying and prevent product slipping
  • Guide profiles – Ensure accurate belt tracking and reduce misalignment
  • Sidewalls – Prevent product spillage, ideal for bulk material handling

Selection Criteria for Homogeneous PU Conveyor Belts

When selecting the right homogeneous PU conveyor belt, consider the following:

  • Drive type: Choose between 25mm or 50mm pitch, friction drive or positive drive (sprocket-driven)
  • Operating environment: Temperature, humidity, frozen conditions, and exposure to oil, grease, or chemicals
  • Hygiene & food safety: Ensure compliance with food-grade standards and easy cleaning capability
  • Load capacity & dimensions: Select appropriate thickness, width, and load-bearing capacity
  • Special features: Sidewalls, guides, drainage holes, cleats for optimized conveying
  • Durability & maintenance: High wear resistance and easy maintenance to minimize downtime

Conclusion

We supply a full range of 25mm pitch homogeneous PU conveyor belts from leading brands such as Amega, Habasit, Mafdel, Ino Belts, Yongli, and Forbo. These products offer superior durability, excellent hygiene performance, and meet the strict requirements of food and industrial applications.

With a positive drive design, these belts ensure stable operation, prevent slipping and misalignment, and allow for easy cleaning and maintenance—making them a reliable and cost-effective solution for modern production systems.
