RF2060 Attachment Chain is a double-pitch conveyor chain designed for medium to heavy-duty applications. It is developed based on the ANSI 60 standard with an extended pitch of 38.10 mm. One of its key highlights is the side plate thickness of up to 3.2 mm, significantly improving tensile strength and impact resistance in high-load conveyor systems. Thanks to its robust structure and flexible attachment options, this industrial chain is widely used in automotive, woodworking, food processing, and heavy logistics industries.
What is RF2060 Attachment Chain?
The RF2060 attachment chain belongs to the medium-to-heavy duty conveyor chain category.
- Structure: Based on ANSI 60 standard but with a double pitch (38.10 mm).
- Key feature: The side plate thickness reaches 3.2 mm, making it stronger than standard double-pitch chains, enhancing load capacity and durability under harsh working conditions.
Technical Specifications
| Specification | Symbol | Value |
|---|---|---|
| Pitch | P | 38.10 mm |
| Inner width | W | 12.70 mm |
| Roller diameter (Type S) | R | 11.91 mm |
| Roller diameter (Type R) | R | 22.23 mm |
| Pin diameter | D | 5.96 mm |
| Pin length | L1 | 14.55 mm |
| Pin length | L2 | 16.55 mm |
| Plate thickness | T | 3.2 mm |
| Plate height | H | 17.2 mm |
| Allowable load (Steel) | 6.28 kN | |
| Allowable load (Stainless Steel) | 1.03 kN | |
| Allowable load (Plastic) | 0.54 kN | |
| Weight (Type S) | 1.51 kg/m | |
| Weight (Type R) | 2.19 kg/m |
Compatible Attachments
RF2060 supports various attachment types for flexible installation:
- A1 / A2: Single-side attachments (1 or 2 holes)
- K1 / K2: Double-side attachments for crossbars
- SA / SK: Vertical attachments for partitions
- EP: Extended pins for special fixtures
Key Advantages of RF2060 Attachment Chain
High load capacity & durability
With thicker side plates (3.2 mm), RF2060 offers superior tensile strength and impact resistance compared to RF2050, making it ideal for heavy-duty operations.
Stable and smooth operation
The double-pitch design optimizes power transmission, reducing vibration and wear during long-term use.
Flexible attachment options
Supports multiple attachment types (A, K, SA, SK, EP), allowing easy integration into various conveyor systems.
Material versatility
Available in carbon steel, stainless steel, or plastic. Stainless steel versions are especially suitable for humid or food-grade environments due to corrosion resistance.Easy installation & maintenance
Standardized design simplifies assembly, replacement, and maintenance, minimizing downtime and operational costs.
Applications of RF2060 Attachment Chain
- Automotive industry: Tire and chassis assembly conveyors
- Wood industry: Transport of large panels and raw materials
- Food industry: Washing and drying systems (stainless steel version)
- Logistics: Pallet and heavy-duty box conveyors
Where to Buy Reliable RF2060 Attachment Chain?
Choosing the correct specifications is crucial for ensuring smooth and stable conveyor operation. A properly selected chain not only enhances performance but also reduces maintenance costs and extends equipment lifespan.
For medium to heavy-duty conveyor systems, investing in a high-quality RF2060 attachment chain from the beginning is a long-term solution that guarantees durability, load capacity, and operational stability.
Belota Co., Ltd. is a trusted supplier of industrial conveyor chains, offering a wide range of attachment configurations tailored to specific application requirements. With an experienced technical team, Belota provides expert consultation to help you select the most suitable chain for your system.
